CADDX Neuron F4 F60A BLS ESC is a high performance flight controller and ESC combo designed for FPV drones. It is equipped with an STM32F405RET6 main control chip, an ICM42688 gyroscope, and an integrated 16MB Flash memory. The device supports a wide range of input voltages and has a dual BEC.
Main chip: STM32F405RET6
MCU: STM32F405RET6
Gyro sensor: ICM42688
BEC: 5V/3A; 10V/2.5A
Memory: 16MB
Firmware: HAKRCF405V2
Input voltage: 2S~6S
Continuous current: 60A
Maximum current: 70A (Lasts for 10 seconds)
Current ratio: 160
Software for setting parameters: BLHeliSuite16.7.14.9.0.3
Weight: 23 g
Dimensions: 64x64x35 mm
Standard protocols: Oneshot42, Oneshot125, Dshot150, Dshot300, Dshot600, PWM, Multishot
